Specification

Hardware

CPU

AR9341

RF

2T2R

Memory

32MB

Flash

8MB

Interface

2 x RJ-45 for 10/100 Mbps

1 x Reset button(reset & factory defaults)

1 x Power DC Jack

Power

12V/1A DC Jack or 24V/0.5A Passive POE

RF radio

Frequency

802.11b/g/n

2.4~2.4835GHz

U.S.,Europe and Japan product covering 2.400 to 2.4835 GHz,programmable for different country regulations

Modulation

OFDM = BPSK,QPSK, 16-QAM, 64-QAM

DSSS = DBPSK, DQPSK, CCK

Throughput

300 Mbps

Sensitivity

802.11n(2.4GHz)HT20

802.11g

802.11b

-92dBm @ MCS0

- 93dBm @ 6Mbps

- 94dBm @ 1Mbps

-73dBm @ MCS7

- 75dBm @ 54Mbps

- 85dBm @ 11Mbps

Output Power

Radio1(WLAN1)

802.11n(2.4GHz)(± 1.5dBm)

802.11g(± 1.5dBm)

802.11b(± 1.5dBm)

25dBm @ MCS0~2/MCS8~10

27dBm @ 6~24Mbps

30dBm @ 1~11Mbps

25dBm @ MCS3/MCS11

27dBm @ 36Mbps

25dBm @ MCS4/MCS12

26dBm @ 48Mbps

25dBm @ MCS5/MCS13

26dBm @ 54Mbps

24dBm @ MCS6/MCS14

24dBm @ MCS7/MCS15

Antenna

Internal 14dBi directional ANT

SoftWare

Operation Mode

Access Point / Ap Client /Gateway / WISP

Protocol/Standard

IEEE 802.3(Ethernet)

IEEE 802.3u(Fast Ethernet)

IEEE 802.11b/g/n(2.4G WLAN)

Wireless

Auto-channel selection

Multiple SSID (4 SSID)

WDS AP / WDS Bridge

BSSID

Security

WEP Encryption-64/128/152 bit

WPA/WPA2 Personal (WPA-PSK using TKIP or AES)

WPA/WPA2 Enterprise (WPA-EAP using TKIP)

Hide SSID

MAC/IP address &URL filtering

Wireless STA (Client) connected list

System Settings

Web-based configuration(HTTP/Telnet)

Firmware Upgrade

Upgrade firmware via web browser or TFTP

Administration

Admin Password can be configured

System monitoring

Status in hand , useful statistic and Event log

Logs

Supports local logs,logs  host,logs file export

Reset

Renew system or restore to factory defaults

Backup

Restore settings & configuration of the device to local file

Working Condition

Temperature

Working: -20°C~70°C

Storage: -30°C ~85°C

Humidity

5%~95%( typical)
