3G 4G Portable WiFi Router with Power Bank
Bookmark and Share

  • Platform

    CPU

    MT7628NN  580MHz

    WiFi

    2.4Ghz, IEEE 802.11b/g/n

    Technical

    Flash

    16M

    RAM

    128M

    Channel

    1-13 channel

    Transfer speed

    300Mbps

    Sensitivity

    11Mbps: ≤-90dBm, 54 Mbps: ≤-72dBm
    HT20 QMCS7: ≤-69dBm
    HT40 MCS7: ≤-66dBm

    Default LTE module Frequency Band ( Optional )

    FDD-LTE

    B1(2100MHz),B3(1800MHz),B7(2600MHz),B20(800MHz)

    Interface

    RJ45

    1 * 10/100MAdaptive WAN / LAN port (Auto MDI / MDIX)

    Antenna

    2 * 3dBi Internal Antenna

    PCIe connector

    Support

    Button

    Power/ Reset

    Micro SD

    Up to 32GB

    SIM

    Support

    USB

    1 * USB 2.0

    Power bank

    Built-in 7500mAh Lion battery

    Charge

    Input 5V,1A/ Output 5V,1A

    Software

    System

    Open-WRT

    Security modes

    Open/ WEP/ WPA-PSK/ WPA2-PSK

    Environment

    Storage Temperature

    -40˚C80˚C

    Storage Humidity

    5% RH to 95% RH (non-condensing)

    Operate Temperature

    -20˚C60˚C


  • Download
  • Description

    OMY-LT01 is IEEE 802.11b/g/n Multi-function 300Mbps router with 3G/4G Router,AP,Repeater,Power bank function, can work as online player,offline APP promote,the SD card can expand to 32G,support download and upload document .This device is long standby design with Built-in 7500mAh battery very ideal for outdoor use and Car / Bus WiFi share use. With the latest MT7628NN chipset this device also support Open-WRT.

    Features

    • Multi-function 3G/4G Router/AP/Repeater/Power bank
    • 300Mbps Wifi Router,Support 30 people simultaneously use
    • APP(APK),based on Dlan,Online Player,Download & upload
    • Built-in 7500mAh Polymer Battery,Super Standby
    • SD card expandable up to 32Gb
    • Pre-load Open-WRT system
