Specification

CPU

Mediatek MT7620A

Hardware

Flash

16MB (32MB MAX.)

SDRAM

DDR2 128MB

Antenna

2 * 2.4GHz IPEX Connector

Interface

1 * WAN Port ,

4 * LAN Port ,

1 * SIM Card

1 * TF Card,

1 * MiNi PCIe (built-in)

1 * USB 2.0,

1 * DC Socket

Button

RESET

LED

WAN,LAN LINK/ACT

Software

System

OPEN-WRT

Work Mode

AP,Router,Client,Repeater,Bridge

WAN Type

Dynamic IP /Static

IP/PPPoE ,PPTP/L2TP/BigPond

Port Forwarding

Virtual Servers,

Port Triggering,

UPnP,

DMZ,

FTP Private Port

Wireless

Standard

IEEE802.11b/g/n ,

IEEE802.1x ,

IEEE802.3/3u

Frequency Range

2.4-2.4835GHz

Signal Rate

300Mbps

Transmit Power

100MW

Data Transfer Rate

802.11n:40MHz

(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps);

20MHz

(144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
801.11g:

(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b:

(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)

Security Encryption

64/128/152-bit WEP/WPA/WPA2 ,WPA-PSK ,WPA2-PSK

Power Supply

DC 12V / 1A

Environment

Storage Temperature

-45˚C～85˚C

Operate Temperature

-25˚C～75˚C

Operating Humidity

95% ( Non-condensing)
