CPU

QCA9344 + AR9382

Hardware

Flash

16MB

SDRAM

128MB DDR2

Antenna

External antenna with Ipex connector

Ethernet Port

100Mbps WAN x 1 ,

100Mbps LAN x 4,

Interface

USB2.0 x 1 ,

Micro SD x 1,

SIM card x1,

Button

Reset

LED

Power,LAN Link/Act,WIFI 2.4G,5.8G

Software

System

OPENWRT 14.07

Work Mode

AP,Router

WAN Type

Dynamic IP /Static

IP/PPPoE ,PPTP/L2TP/BigPond

Port Forwarding

Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port

Wireless

Standard

IEEE802.11b/g/n/ac

Frequency Range

2.4Ghz,5.8Ghz

Signal Rate

600Mbps

Transmit Power

2.4G-27dBm,5.8G- 25dBm

Data Transfer Rate

802.11ac:600Mbps

802.11n:40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps);

20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
801.11g:(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b:(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)

Security Encryption

64/128/152-bit WEP/WPA/WPA2 ,WPA-PSK ,WPA2-PSK

Power Supply

12V DC

Environment

Storage Temperature

-45C~85C

Operate Temperature

-25C~75C

Operating Humidity

95% ( Non-condensing)
