300Mbps Ceiling mounted Access Point
Bookmark and Share
  • Platform

    CPU

    Mediatek MT7620N

    Hardware

    Flash

    8M

    SDRAM

    64M

    Antenna

    Internal 2*5dBi antenna

    Interface

    1 WAN ,1 LAN ports

    Button

    Reset

    LED

    WAN,LAN LINK/ACT

    Software

    System

    OPEN-WRT

    Work Mode

    AP,Router,Client,Repeater,Bridge

    WAN Type

    Dynamic IP /Static

    IP/PPPoE ,PPTP/L2TP/BigPond

    Port Forwarding

    Virtual Servers, Port Triggering, UPnP, DMZ,FTP PrivatePort

    Wireless

    Standard

    IEEE802.11b/g/n ,IEEE802.1x ,IEEE802.3/3u

    Frequency Range

    2.4-2.4835GHz

    Signal Rate

    300Mbps

    Transmit Power

    20dBm (100MW)

    Data Transfer Rate

    802.11n:40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps);

    20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
    801.11g:(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
    802.11b:(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)

    Security Encryption

    64/128/152-bit WEP/WPA/WPA2 ,WPA-PSK ,WPA2-PSK

    Power Supply

    Passive PoE 24V or DC 9-24V

    Environment

    Storage Temperature

    -45˚C85˚C

    Operate Temperature

    -25˚C75˚C

    Operating Humidity

    95% ( Non-condensing)


  • Download
  • Description

    OMY-WR300M is Mediatek MT7620N chipset based Ceiling AP,dual powered method Passive PoE or DC,support Preloading OpenWRT,with beautifual high-end case design case OMY-WR300M is a ideal wifi expand device for small Hall ,bar and hotel etc.

    Features


    • Wireless speed up to 300Mbps
    • Mediatek chipset MT7620N
    • 1 WAN port,1 LAN port
    • Open-WRT system preloaded
    • Ceiling Mount design
    • Powered by Passive PoE 24V or DC 9-24V


    ,
